SHOTOVER F1
SHOTOVER F1 Australia – Recalibrating Versatility
The SHOTOVER F1 adapts to your needs, from broadcast to features. It’s the most advanced and flexible mount in Australia.
A 6 axis gyro stabilized platform delivers unshakable stability with look down capability for use inverted, or right side up on almost anything that moves.
It rigs fast and accommodates a wide range of cameras and lenses, including the Arri Alexa M, Red Epic, Canon C500 and Sony F55 & HDC-2500, for the look you want.
While its compact carbon fiber construction means it ships as excess baggage on commercial flights worldwide with no export restrictions.
SHOTOVER F1 System Features
- Quickly and easily interchange multiple cameras and lenses
- Compact size and weight allows affordable transport as freight or excess baggage
- No ITAR restrictions or EAR licensing requirements
- Compatible with most FAA and EASA approved aircraft mounts
- Easily integrated onto a wide variety of mounting platforms
- 6-axis gyro stabilized with look down capability
- Windowless operation option for brilliant imagery without reflections
- Fiber optic video data transfer for clean 3GHz imagery
- State of the art electronics and design techniques deliver unshakable stability and ultimate functionality
- Customizable graphics overlay for real time operator feedback
- Auto or Steerable horizon with the most advanced steering capabilities on the market
- Inverted operation using auto-position detectors
- Remote controlled polarized filter rotation, rain deflector and other accessories available
SHOTOVER F1 Specifications
STABILIZATION
- 6-axis with no gimbal lock
- High performance non-ITAR sensors
- Distributed Multi-processor closed loop servo control system
- Proprietary gimbal control algorithms
GIMBAL FIELD OF VIEW
- Pan: 360 degrees continuous (via electrical and optical rotary joints)
- Tilt: +45 to -140 degrees
- Roll: +/-85 degrees (steerable or auto horizon)
- Max slew rate: 100 deg/sec
DATA / COMMUNICATION
- Fiber Optic lines
- CAN Bus
- RS 422 Serial Bus
- Ethernet
WEIGHT
- Turret with max payload less than 59kg (130lbs)
- Operator control unit 2.7kg (6lbs)
- Junction control box 4kg (9lbs)
- External cable set: 2.5kg (5.5lbs)
POWER
- 19-72 VDC
- 12 Amps Max Draw (at 28V)
ENVIRONMENTAL
- Operating Temperature: -20 to +50 degrees C
OPERATOR CONTROL UNIT
- Lightweight
- Customizable video overlay (Monitor Output)
- Recess for camera remotes such as: Sony RM-B750, Arri RCU-4
- Other control layouts available upon request
Our camera mounts operate around Australia, New Zealand and Asia. Sydney • Melbourne • Brisbane • Canberra • Cairns and the Great Barrier Reef • Adelaide • Perth • Darwin • Tasmania • Gold Coast • The Kimberley • Alice Springs • Uluru (Ayres Rock) • Auckland • Queenstown • China • Indonesia • Thailand • Malaysia and across the Asia Pacific •
